New Small Automatic Chocolate/Sugar/Powder Coating Pan 6kg to 150kg For Nuts/Dry Fruits/Pill

Short Description:

This machine is used for sugarcoat tablets and pills for pharmaceutical and food industries.It also can be used for roll-fry beans,nuts or seeds.The leaning angle is adjustable, and electrical stove or gas stove can be placed underneath as heating device.Single electrothermal blower, the wind outlet pipe(adjustable wind volume) can be put into the pot as heating or cooling.

Item No: LST PGJ

Capacity: 6kg-150kg

Dimensions: 0.70（L)*0.90(W)*1(H)m

Certification: CE

Customization: for 1 set

EXW Price: /

Send email to us Download as PDF

Product Detail

Product Tags

●Product Introduction

This machine can be used for Coating and polishing chocolates with various shapes,such as round, oblate, oval,sunflower seed shaped,cylindrical etc, making it glossy,and shining with lustre on the surface. Moreover, chocolates shall look more delicate after being polished.The cylindrical chocolates are usually wrapped by multi-colored aluminum foil,the wrapping paper fits better with the chocolate after being polished,the geometrical structure becomes clearer. This polishing pot also applies for enrobing nubbly products such as flour-coated peanuts, hard/soft candies,bubble gums,pills,etc.

LST Machinery, founded in 2009,which is located in Chengdu ，which is one standard and professional company for manufacturing & trading .We are highly successful in chocolate food making machine and packing machine etc.
5 top technology and research and development staffs , ,3 different high and new technologies will be carried out each year.More than 30 manufacturing persons and good sales team and after-service supports.
OEM supporting ,professional comprehensive solutions and long-term cooperation.

●Features

1. Multifunctional, flexible and wide application
2. Adjust speed+Adjust angle+Adjust hot air+Normal room air
3. Attached device include:
a.Single electrothermal blower, the wind outlet pipe(adjustable wind volume) can be put into the pot as heating or cooling.
b.Heat(temperature) can be adjusted.
c.Speed-adjustable motor

●Application

●Parameter

Model	PGJ-400	PGJ-600	PGJ-800	PGJ-1000	PGJ-1250	PGJ-1500
Diameter of Sugar Coating Pot	400mm	600mm	800mm	1000mm	1250mm	1500mm
Speed of Sugar Coating Pot	32r/min	32r/min	28r/min	28r/min	28r/min	28r/min
Main Motor Power	0.55kw	0.75kw	1.1kw	1.5kw	3kw	5.5kw
Blower Power	60w	60w	250w	250w	250w	250w
Electric Heating Power	1kw	1kw	2kw	2kw	3kw	6kw
Production Capacity	6kg/batch	15kg/batch	20-40kg /batch	40-60kg /batch	60-100kg /batch	100-150kg /batch
Overall Dimension (lengthwidthheight)	600550880mm	700700 1100mm	925900 1500mm	110011001600mm	120012501800mm	120015002000mm
Weight	45kg	66kg	126kg	138kg	165kg	200kg
Function:Adjust speed+Adjust angle+Adjust hot air+Normal room air

●Flexible Layout

●Operation Process

Coating powder:
-manual put cashew into coating pan
-open coating pan
-manual spray powder
-manual outlet finished products
-manual wash coater

Coating Chocolate:
-manual put almond into coating pan
-auto spray chocolate, open cold air to 180 degree coat
-open hot air to modify
-open cold air to coat
-manual outlet product
-put it into lower humidity and temperature place to dry
-polishing

Coating Sugar:
-manual put material into coating pan
-open machine and air
-manual spray sugar syrup
-manual spray powder
-cycle
-manual outlet product
-put it into lower humidity and temperature place to dry
-coloring
-polishing
