LST 2022 latest cooling tunnel with enrobing machine for bulk production
●Product Introduction
LST use stainless steel 304 and import compressor from USA and frequency converter greatly improves the stability and durability of this device. Cooling effect is stable and the whole process is clean.
●Features
1.Cooling tunnel are equipped with 2 sets of 5P refrigeration systems. Direct touch cooling on bottom side and indirect top cooling design.
2.All stainless steel and food grade conveyor belt which in compliance with food hygiene and safety standard.
3.Two stages or even more stages of cooling, such as fresh air cooling and refrigeration cooling,etc. The multi-stage cooling design makes it energy saving, fast cooling, easy operation,etc.
4.Tunnel cover adopts the latest design concept, fully covered and sealed design greatly avoid energy loss.
5.The tunnel cover can be opened or removed easily, no tools needed,easy for cleaning.
●Application
●Parameter
| Model | LST400C | LST600C | LST900C |
| Conveyor Width | 400mm | 600mm | 900mm |
| Conveyor Speed | 0-8 m/min | 0-8 m/min | 0-8m/min |
| Total Power | 12kw 380V/400V | 12kw 380V/400V | 15kw 380V/400V |
| Cooling Unit | 2*3P | 2*5P | 3*5P |
| Main Motor | 1.5KW | 2.2KW | 3KW |
| Belt type | 1.5mm white PU belt | 1.5mm white PU belt | 1.5mm white PU belt |
| Temperature | 1℃-10℃ | 1℃-10℃ | 1℃-10℃ |
| Cooling speed | 50-150kg/h | 100-250kg/h | 200-300kg/h |
| Dimension | 6000*850*1500mm | 10000*900*1500mm | 15000*1300*1500mm |
●Samples
●Flexible Layout
●Video
