Healthy Snack Hot Chocolate Dispenser Storage Holding Tank
- Applicable Industries:
-
Food & Beverage Factory
- Brand Name:
-
neste
- Place of Origin:
-
Sichuan, China
- Voltage:
-
330/380V
- Power(W):
-
4kw
- Dimension(L*W*H):
-
1200*1000*1900mm
- Weight:
-
500kg
- Certification:
-
CE ISO
- Warranty:
-
1 year
- Application fields:
-
Snack food factory
- Raw material:
-
chocolate
- Condition:
-
New
- Application:
-
Chocolate
- After-sales Service Provided:
-
Engineers available to service machinery overseas, Field installation, commissioning and training
Healthy Snack Hot Chocolate Dispenser Storage Holding Tank
Specifications
Chocolate tempering machine :
1, temperature adjustment
2, melting and storage function
3, with scraper, mixer and stir device
Features of Chocolate Melting machine :
Name |
Model |
Main use |
Volum |
Voltage |
Over Dimensions |
Mini melting tank |
BWG04 |
Melt,storage,Heat preservation |
4KG |
Single-phase,220V-240V |
240*295*230mm |
Mini melting tank |
BWG08 |
Melt,storage,Heat preservation |
8KG |
Single-phase,220V-240V |
410*295*230mm |
Mini melting tank |
BWG18 |
Melt,storage,Heat preservation |
18KG |
Single-phase,220V-240V |
605*350*230mm |
Tempering tank |
TWG75 |
Tempering&Mixer |
75KG |
3-phase,415V |
900*1400mm |
Tempering tank |
TWG150 |
Melt,storage,Heat preservation |
150KG |
3-phase,415V |
900*1500mm |
Heat preservation tank |
BWG250 |
Heat preservation&Mixer |
250KG |
3-phase,415V |
1100*800*1600mm |
Features of Chocolate tempering machine :
1, temperature adjustment
2, melting and storage function
3, with scraper, mixer and stir device
4, stainless steel
5, digital temperature control system
6, with water interlayer heating equipment, can be used for external heating and heat preservation
Introduction of Chocolate tempering machine :
Our chocolate melting and tempering mixer machine tank from 75kg to 6000kg, and we also can specially made according to your special needs. It can be used for melting, storage and heat maintaining for chocolate, axunge and similar coating materials.
The stainless steel tank has a sandwich with constant temperature control, and a strong mixing and scraper device inside.
Other components including a water interlayer heating equipment, can be used for external heating, heat preservation and insulation.
Parameter of Chocolate tempering machine :
Chocolate tempering machine:
Model |
Max capacity |
Heating style |
Power |
Power supply |
Shell size |
Net weight |
Price |
LSTTW10 |
10kg/batch |
electrical heating |
1.2kW |
Single phase/220V |
560 x 600 x 550mm |
40kgs |
USD2500/ FOB SHANGHAI |
LSTTW30 |
30kg/batch |
electrical heating |
3kW |
Single phase/220V |
900 x 750 x 950mm |
180kgs |
USD4000/ FOB SHANGHAI |
LSTTW60 |
60kg/batch |
electrical heating |
4.5kW |
Single phase/220V |
1100 x 800 x 1150mm |
260kgs |
USD6500/ FOB SHANGHAI |
Option:
If need the water chiller to provide cooled water to LST-60 for tempering function (for pure chocolate tempering), the price for the water chiller is:USD3500.-/ set.
Delively date:
Within 30 days upon the receipt of the down payment
Terms of payment:
50% by T/T as the down payment, the balance shall be paid by T/T before shipment.
In stallation and trial run:
The equipment layout design, assembling and installation, start-up and local team training will be FREE. But if the machine is exported to other countries, the buyer should be responsible for the round-air tickets, local transportation, board & lodging, and US$80/day/person for the pocket money to our technicians.
Warranty:
The seller guarantees the quality of the products for 12 months since the date of installation. During the warranty period, any problems/defaults happen on the hard parts of the machinery, the buyer will replace the parts at the seller’s cost. If the defaults are aroused by the defaulted operations, or the buyer needs the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
Utilities:
The buyer should prepare sufficient electric power, water, which are suitable to be connected to our machinery before the arrival of our machinery.
Validity:10 days.
Founded in 2009, Chengdu LST has professional R&D team and specialized equipment, specializes in manufacturing middle-high class of chocolate equipment, such as chocolate molding Machines, chocolate coating machines, chocolate enrobing machines, chocolate & grain mixture moulding machine, ball mill, etc.
Our chocolate equipment have been popular in the food industry. At the same time, the products produced by our equipment are also in the forefront of the candy industry as well. Besides the domestic market, our equipment have been widely sold to Germany, India,Vietnam, South Korea, Canada, Australia, Russia, Ecuador, Malaysia, Romania Israel,Peru and many other countries in the world.
We provide OEM service. At the same time, life-time after-sales service for our equipment are provided to world wide customer and we are looking forward to your visit.
1. Payment: T/T in advance. 40% down payment, 60% against acceptance from customers
2. Strict with complete testing and well adjustment according to customers’ requirement before shipment.
3. Customization is available.
5. What’s the information should I let you know if I want to get a full quotation?
Bag type, size, weight of material, type of material, thickness, printing, colors, quantity
6. When we create our own artwork design, what kind of format is available for you?
The popular format: AI, JPEG, CDR,PSD, TIF
7. Wooden case packed with machine and English manule
8. Transformer is provided
9. Technical manual in English is provided
10. The machine is stainless steel
11. In the line of exporting packing material
