Fully automatic 200-400kg/h polishing machine chocolate coating machine for sale

Short Description:

Send email to us Download as PDF

Product Detail

Product Tags

Overview

Quick Details

Condition:: New

Applicable Industries:: Food & Beverage Factory

After Warranty Service:: Video technical support, Online support

Local Service Location:: Canada, Pakistan, India, Russia, Morocco, Uzbekistan

Showroom Location:: None

Brand Name:: LST

Place of Origin:: Sichuan, China

Voltage:: 380V/50HZ/Three Phase

Power(W):: 24Kw

Dimension(L*W*H):: 2550*1600 *2650mm

Weight:: 800kg

Certification:: CE

Application fields:: Snack food factory, Bakery

Machinery Function:: coating

Raw material:: Milk, Corn, Fruit, Wheat, Nuts, Soybean, Flour, Vegetables, Water, peanuts, raisins , almonds M&M chocolate beans

Output product name:: chocolate

Key Selling Points:: Multifunctional

After-sales Service Provided:: Engineers available to service machinery overseas

Product name:: belt type chocolate coating machine

Matched machine:: chocolate polishing machine

Usage:: chocolate/candy/food coating and polishing

Capacity:: 200-400kg/h

Refrigerant:: matched cooling system

Compressor:: 0.4Mpa

Color:: SS color

Feature:: easy Operate

Warranty:: 1 year

Fully automatic 200-400kg/h polishing machine chocolate coating machine for sale

Product Description

Chocolate Coating&Molding machine and Chocolate Polishing machine are mainly used in stuffed products with peanuts,almonds,raisin,puffed rice balls,Jelly candies, hard candies ,QQ candies etc.

Output	200-400kg/h 330L/batch
Total Power	12KW
Dimension	2450-1650-2250mm
Net Weight	800kg
Belt Speed	5-20m/min
Belt Width	1650mm
Compressed Air	0.4MPa
Power Supply	380V 50HZ or customized

Production process

Chocolate coating -air dry and solidify-polishing

For special product

1.For fragile products and puffed product, Diameter ≥4mm, stuffed material ≤250 liters. The more fragile, the less material.

2.For products with corner and edges,round shape and consistent thickness is not suggested.

3.For adhesive product, put less adhesive material. In case materials stick together and effect the shaping.

4.For chocolate paste, it is necessary to filter before add in to avoid block of spray nozzle.

Products show

Main consist of 4 machines

(1).chocolate coating machine

(2).chocolate material feeding system

(3).8P industrial refrigeration units(water cooling and forced air cooling)

(4).chocolate polishing machine

Production condition

1.Single room for chocolate coating machine and chocolate coating machine .Must install air-condition and Dehumidity dryer to make room’s temperature ≤20℃ and humidity ≤50%.

2.Both machine can be installed on one room,room area is about 15square.

3.Chocolate after enrob,need air dry to determine on temperature10℃-15℃ and humidity ≤50%.

4.4Mpa compressed air supply,must have air supply connect scochet.

When sign contract ,buyer must explain power supply and frequency first.

Production Condition and Requirements

5.Cooling units’s temperature range 5-10℃,room temperature range 14-20℃,humidity≤50%.

6.Cold storage temperature range 10-15℃,cold storage time range 8-10 hours ,to guarantee chocolate surface’s smooth and harden.

7.Debugger will debug machine and both parts will accept machine according above requirements.If buyer’s chocolate and production condition is not fit ,then make chocolate’s instability and disqualification ,seller won’t take any responsibility.
